BENEFITS
Model P wall fans provide warm air exhaust or fresh air supply. These fans include several different styles of propellers, two-drive configurations, and with a variety of available accessories. The Model P series axial propeller fans are the ideal choice for factory and warehouse applications. All drive frames are built of heavy-gauge construction and built for a lifetime of service.
The powerful TEFC motor provides trouble-free operation. Direct or belt drive models are available.
- Model P fans use a direct drive motor, which has no belts to replace or pulleys to adjust for simplified operation.
- Model PB fans use a belt drive motor, which includes a variable pitch drive for precise speed control and quieter operation.
These sidewall fans are perfect for factories, forges, and any industrial or commercial facilities. They provide powerful, warm air removal in exhaust mode and a cooling breeze for workers when used in supply mode. Model P wall fans are the solution for improving ground floor airflow in any industrial space.
Features
- Sizes:
- Direct Drive: 24” – 54”
- Belt Drive: 24” – 72”
- HP: 0.33 – 15 HP
- Performance: 250 – 100,000 CFM
- Static Pressure: 1.25” w.g.
- Motor: Heavy-duty, totally enclosed fan cooled (TEFC) motor provides years of trouble-free operation.
- Drives: Direct or belt drive units available. Belt models contain a variable pitch drive.
- Propeller: High performance dynamically balanced propeller for ideal performance and efficiency.
- Housing: G90 galvanized steel (mill finish) with flanges for mounting. protective finish.
- Frame: Heavy-gauge construction
- Design: Deep spun venturi panel provides superior strength and higher efficiency.
Options
- Wall collar.
- Wall housing.
- Dampers: gravity or motorized.
- Finishes: epoxy, polyurethane, custom.
- Filter box (supply only).
- Guards & screens (bird & insect).
- Reversible propeller.
- Disconnect.
- Weather Hoods
- 45 (Relief)
- 90 (Intake)
